SMT-M230

우수한 품질의 무선단말기 스마트로 SMT-M230

모바일 APP와의 연동을 통한 다양한 결제 지원

  • 보안인증 단말기

  • 휴대용 무선 카드 단말기

  • 최소형 고급디자인
    적용 및 휴대 가능

  • 스마트폰에서 어플을 통해
    간편하게 카드결제 가능

휴대가 간편한 블루투스
프린터 탑재 초소형 단말기

다음과 같은 분들에게 추천합니다. 외부 결제가 많은
영업직 / 기존 카드 결제기 금액이 부담되는 가맹점주 야외 이동식
매장 / 방문 판매 방문업자 종이 영수증 출력이 필요하신 분

SMT-M230
SMT-M230 SMT-M230 SMT-M230

SPECIFICATION

SPECIFICATION 목록
내용
Printing method Direct thermal line printing
Character size Eng. : 9x24dots, 12x24dots
Kor. : 16x24dots [24x24dots]
Resolution 203dpi, 8dots/mm
Print width 2-inch (48mm, 384dots)
Printing speed 80mm/sec (MAX)
Dimensions (WxDxH) / Weight · Bluetooth Ver4.0
· USB
Interface TDES
Paper supplied Thermal roll paper, (58mm wide, 40ø),
Paper thickness : 60±5㎛
Driver/th> Microsoft Windows 98/ME/VISTA/ 10
Windows CE, Linux, Android, Blackberry
MSR [option] ISO 7810/7811/7812
Triple tracks (1&2&3 Tracks) Reading
**Supports 3DES & AES encryption (3DES is standard) [option]
**DUKPT key management
Smart card reader [option] ISO 7816 Compliant (EMV level 1/2 Certified) /
T=0, T=1 support / 1 SAM (Security Application Module)
LCD 128*32 Dots FSTN(Blue LED Backlight)
Battery Rechargeable 7.4V DC 1,100 mAh (Li-ion), 1 hour continuous printing
AC adapter Input(100~250VAC, 50~60Hz)
Output(8.4VDC/0.8A), 4hours full charge time
